UL2725 USB CABLE 4C AWG28 TC7/0.127 BLACK

更新：2016/10/17 23:37:45 点击：2046

产品介绍

UL2725 USB CABLE 4C AWG28 TC7/0.127 BLACK

CABLE DATA
● Conductor:Tinned Plated Copper				● Rated Voltage: 30V DC
● Operating Temperature: 80℃				● RoHs Compliant
● Flame resistance: VW-1 or FT1				● Standard: UL Subject 758

Cores:
● Conductor Size: AWG28 TC7/0.12±0.008MM(Tinned Copper)				● Insulation Material : PVC
● Insulation Thickness: 0.23MM				● Insulation OD: 0.85 ± 0.1MM
● Color: Black, Red, White, Green				● No marking

Twisted:
● 4 cores twisted together.

Jacket:
● Material: PVC				● Color: Black
● Wall Thickness (NOM): 0.5 MM				● Finish OD: 3.1 ± 0.15MM
